VOSCOM 8-Channel Duplex RS232 Serial Data Fibre Optic Modem

VOSCOM 8-Channel Duplex RS232 Serial Data. Fibre Optic Modem

System Design

Fiber Optic Serial Data Transmitter & Receiver

VOS-8FOM-D232T/R provides for the digital transmission of 8-Channel duplex Rs232 serial data signal over one fiber. Applications for PTZ Control for CCTV Surveillance Systems, Access Control System, Industirlia control, Data Control for Manufacturing / Assembly Platforms, ITS...etc.

Stand-alone or rack-mount. All units of VOS-8FOM-D232T/R come in an insert card version.The cards can be inserted into our 14-slot, 19inch 4U or 6U rack-mountable card cage (VOS-CH04 or VOS-CH06). The card version of this model require two slots widths.

Single-Mode or Multi-Mode, VOS-8FOM-D232T/R can support FC /PC or ST/PC Optical connector, can be used in Daisy-Chain system (Need to customize). The Transmission distance range according to the Optical Budget. Manufacturer's standard is: Single-mode 20km or Multi-mode 2km.

Features

•Support Point-to-Point or Daisy-Chain connection
•Rs232 Serial data over one fiber
•Multi-mode Fiber Support for Distances up to 2.0 km
•Single-Mode Fiber Support for Distances up to 100 km
•LED Status Provide Rapid Indication of Operating Parameters
•No EMI or RFI and no ground loops
•Stand alone or rack-mount
•Produce according to customer's specifications,providing OEM

Price is for a "SET", includes Transmitter and Receiver, and their power supplies. Pricing is for Single-mode 20km or Multi-mode 2km models. This model is common, inquiries for custom models are welcome.

Important Note When Ordering This Product: Please advise us if you require:

1. The fibre mode to be “Single-Mode” or “Multi-Mode”.
2. “FC/PC” or “ST/PC” optical connectors.

To advise us of the above specifications, kindly type your requirements into the "Order Comments" section at the point of submitting your order.
