SpinetiX IBX440 4K60 Digital Signage Media Player - With 4 HDMI Outputs

Product Code: SX-HW-IBX440

Key Features
  • 4x HDMI Outputs: Enables high-resolution 4x4K video walls at 60 fps
  • Perfect Synchronization: Seamless display across multiple screens enabled by latest-gen Intel® Core™ I5
  • DSOS™ by SpinetiX – signage-dedicated lightweight OS
  • Segregated Airflow Cooling: Optimizes performance and reliability, extending player lifespan.
  • 128 GB of internal storage
  • Designed for 24/7 use
  • TAA Compliant: Meets stringent regulatory standards, ensuring compliance and premium quality.
  • 3-year warranty included, extendable to 5
  • Upgradeable To On-Premise Solutions
Enquire Now
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

Spinetix IBX440 4K60 Digital Signage Media Player - With 4 HDMI Outputs

SpinetiX iBX440 is the digital signage player purpose-built for making video walls accessible to everyone. With four 4K HDMI perfectly-synchronized outputs at 60 fps, a cutting-edge Intel® Core™ i5 powerhouse, DSOS™, and the intuitively designed SpinetiX ARYA™ CMS, the iBX440 makes video wall setup easy on everyone while ensuring visually stunning results.



What sets a SpinetiX player apart?

Robust Hardware - Featuring design dedicated to signage applications, our players are made to deliver content flawlessly 24/7 supporting any signage scenario.

Purpose-Built OS - Powered by DSOS™ – the SpinetiX purpose-built signage OS, our players offer optimal, continuous performance and enhanced security while minimizing resource use.

Powerful Content Tools - Quickly display impactful content with SpinetiX ARYA™ CMS, included with all players. Scale up with our advanced content authoring tool Elementi.



Further Information:

Mounting

The player can be mounted using the included standard-system brackets.

Operating System - DSOS

The embedded DSOS™ is a secured operating system designed for digital signage players, especially for demands of defense, financial, cruise vessel and other high-availability scenarios. It cannot be changed in any way, and no other OS can be installed on the player.

DSOS Activation Licenses

The iBX440 players are working out of the box with SpinetiX ARYA™ cloud-based service, without needing a DSOS license, however, not all the players' features are available. More features can be unlocked by purchasing a DSOS license (choose between WIDGETS, KIOSK, or SYSTEMS) and then activating it on your player.

Warranty

We offer a 3 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Hardware Specifications:

Processor Intel® Core™ i5-1145G7E (formerly Tiger Lake)
Memory RAM: 2x 8 GB DDR4-3200
Storage Internal: Industrial 128 GB SSD M.2 M-Key (2280)
External: Flash drive, hard disk (via USB 3.1)
Power 84W power supply adaptor (included), power required: DC +12V 5A
Operating environment Ambient temperature: 32 - 104ºF / 0 - 40ºC
Storage temperature: -4 to 122ºF / -20 to 50ºC
Relative humidity: 10-90% non-condensing
Real-time clock (RTC) Accuracy ±1 min./month, backed by battery (BR2032)
Dimensions W x H x D: 200.8 x 41.2 x 139.3 mm, respectively 7.90 x 1.62 x 5.48 inches
Weight 1.8kg ± 5g, respectively 3.7 lbs

Inputs & Outputs Specifications:

Video Output 4x HDMI Port 2.0b (type A)
  • Resolution: DCI 4K (4,096×2,160), 4K UHD (3840x2160), 1080p (1920x1080), custom resolutions, etc.
  • Aspect ratio: 16:9, 16:10, 4:3 Horizontal / Vertical, custom aspect ratio

Display power saving: DVI DPMS, serial port

Audio output

Digital audio (stereo and 5.1/7.1 surround sound) via HDMI, or any of the USB ports (using a DAC device)

1x Analog line-level audio (stereo) via dedicated 3.5 mm jack port

Network

connectivity

2x Ethernet 2.5 GbE 8P8C port (a.k.a. RJ45), IEEE 802.3ab/802.3u/802.3az/802.3bz standards
  • Protocols: IPv4, IPv6, DHCP, Zeroconf, NTP, SNMPv1/v2c, HTTP/HTTPS, TLS-SRP, 802.1x, user root certificates, WebDAV, SSDP/UPnP, Bonjour, RTSP, RTP, UDP

Remote configuration: Embedded web server, HTTPS with user root certificates, RPC API

USB port 3 x USB 3.1 Type-A, 1x USB 2.0 Type-A
Serial port 1 x RJ45 port dedicated for RS232
