Picture/Display
Display
4K Ultra HD LED
Diagonal screen size (metric)
164 cm
Diagonal screen size (inch)
65 inch
Panel resolution
3840x2160p
Brightness
340 cd/m²
Contrast ratio (typical)
1200:1
Operation Mode
Audio
Sound output Power
20 (2x10) W
Speakers
Sound Features
- DTS-HD
- Dolby Atmos Compatible
- Dolby MS12D
- AC-4
- DTS Studio Sound
External speaker out
1.5W Mono 8 Ohm
Design
Colour
Black
Android TV
Memory size(Flash)
16GB*
OS
Android TV™ 9 (Pie)
Pre-installed apps
- YouTube
- Google Play Store*
- Google Play Movies
- Google Play Games
- YouTube Music
Tuner/Reception/Transmission
Digital TV
- DVB-T/T2/C
- HEVC UHD (up to 2160p60)
IP Playback
- Multicast
- Unicast
- HLS
- OTT App Channels
Analog TV
PAL
Wireless Connectivity
Wireless LAN
Connectivity Side
Common Interface Slot
CI+ 1.3.2
USB1
USB 3.0
Headphone out
Mini-Jack
HDMI1
HDMI 2.0 with HDCP 2.2
Connectivity Bottom
External power
12V, max 1.5A
Ethernet (LAN)
RJ-45
Antenna
IEC-75
External speaker out
Mini-Jack
External Control
RJ-48
USB2
USB 2.0
HDMI2
HDMI 2.0 with HDCP 2.2
HDMI3
HDMI 2.0 with HDCP 2.2
Connectivity Enhancements
HDMI
- ARC (all ports)
- Auto Input Selection
EasyLink (HDMI CEC)
- One touch play
- System Standby
- RC pass through
- system audio control
RJ48
- IR-In/Out
- Serial Xpress interface
Corporate Features
Wired Presentations
- Auto Input Selection
- Auto Power ON
- Auto Power OFF
Wireless Presentations
- Chromecast built-in
- Secure Sharing
- Network-managed Sharing
Signage Functions
- CMND&Create
- Scheduler
- Banners
Control
- Crestron Connected (v2)
- Extron
- Neets
Customizable
- Home Screen
- Location Name
- Device Name
Professional TV Features
Professional Mode
- Switch-ON Settings Control
- Installation Menu Lock
- Menu Lock
- Volume Limitation
Control
- CMND IP Remote Management
- JEDI Android API Control
- JAPIT HTML5 Control
- AppControl
Convenience
- Google Assistant*
- Google Account Login
- >40 Supported Menu Languages
- Weather Forecast
Safety
- Double Isolation Class II
- Flame Retardant
Multimedia
Video playback supported
- Formats: H.264/MPEG4 AVC
- MPEG1
- MPEG2
- MPEG4
- WMV9/VC1
- HEVC
- Containers: AVI, MKV
- VP9
Subtitle formats supported
Music formats supported
- MP3
- AAC
- WAV
- WMA (v2 up to v9.2)
- WMA-PRO (v9 and v10)
Picture formats supported
Supported Display Resolution
Tuner
- T2 HEVC: up to 3840x2160@60Hz
- Others: up to 1920x1080p@60Hz
HDMI
Up to 3840x2160p@60Hz
USB, LAN
- HEVC: up to 3840x2160@60Hz
- Others: up to 1920x1080p@60Hz
Power
Mains power
AC 110-240V; 50-60Hz
Power consumption (typical)
99 W
Power Saving Features
- Eco mode
- Auto switch-off timer
- Light sensor
Ambient temperature
0 °C to 40 °C
Dimensions
Set Width
1446 mm
Set Height
837 mm
Set Depth
76 mm
Product weight
17.6 kg
VESA wall mount compatible
