NETGEAR M4300-28G-POE+ 24-port PoE+ Layer 3 Stackable Fully Managed Switch with 2 x 10GBASE-T & 2 x SFP+ & 1000W PSU

Product Code: NGR GSM4328PB-100AJS

Key Features
  • 24-port 1000BASE-T (RJ45) PoE+
  • 2-port 10GBASE-T (RJ45) all independent
  • 2-port 10GBASE-X (SFP+) all independent
  • 128Gbps non-blocking fabric across 28 ports
  • Out-of-band 1G Ethernet Management port
  • Mini-USB and RJ45 RS232 console ports and USB storage port
  • Full L3 feature set and non-stop forwarding (NSF) stacking
  • Full width form factor with one-unit rack mount kit
  • (GSM4328PB) Ships with one modular APS1000W PSU in first power supply slot
  • Ship with a blank cover in the second power supply slot
$5,299.00 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Estimated Lead time 4-6 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

NETGEAR M4300-28G-POE+ 24-port PoE+ Layer 3 Stackable Fully Managed Switch with 2 x 10GBASE-T & 2 x SFP+ & 1000W PSU

RELIABILITY:

Business Continuity Management - Full-width switches offer dual redundant, modular power supplies (select m4300 models)

High Availability (HA) - Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack

Multi-Resiliency - Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities

PVST+ Interoperability - Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)

Link Dependency - Enables or disables ports based on link state of different ports

Advanced IPv4/IPv6 security - Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation



EASY TO MANAGE:

Simple GUI - Full- functional Web console (GUI) for IT admins who prefer an intuitive graphical interface

Flexible & Efficient - Line-rate Spine and Leaf topologies offer many possibilities for server rooms, branch collapsed cores, or at the edge of growing networks.

Mix & Match Stacking - Stack between 10/40 Gigabit and 1 Gigabit models using any 10G/40G port, with any media type (RJ45, SFP+, DAC cables). Vertical, horizontal, manage as one unit

Room to Grow - With PoE+, plug and play ports, and hot swap, you're ready to grow whenever you need to.

Industry Standard - SNMP, RMON, MIB, LLDP, AAA, sFlow, RSPAN and PTPv2 1-step transparent clock implementation (select M4300 models)



READY FOR AN AV OVER IP:

Zero Touch AV-over-IP - Pre-configured for Out-of-Box L2 Multicast (SDVoE-ready)

No Delay - Non-Blocking Fabric for Near-Zero Switch Latency

NETGEAR IGMP Plus™ - Prevent network flooding with effortless multicast implementation of Layer 2 Multicast



Designed for AV Pros - NETGEAR M4300 Switches

What is AV-over-IP?

Tech Tips: How to Create a Layer 2 VLAN on an M4300 switch:

How to Log in to the NETGEAR M4300 Switch Through the Command Line:

How to Log in to the NETGEAR M4300 Switch Using the Web GUI:

Warranty

We offer a Limited Lifetime warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

  • Hardware Specifications : Model Number: GSM4328PB
  • PoE Budget (110V): 630W w/1 PSU, 630W w/2 PSUs in RPS mode, 720W w/2 PSUs in EPS mode
  • 24 Ports PoE+ Copper 10M / 100M / 1G
  • 2 Ports Copper 100M / 1G / 10G
  • 2 Ports SFP+ 1G / 10G
  • 2 Modular Bays with One (1) 1000W Modular PSU included APS1000W
  • 128 Gps Switching Fabric
  • Fixed Fan Front-to-Back 39.8dB
  • Management Options : Ethernet: Out-of-band 1G port (Front)
  • Console: RJ45 RS232 (Back)
  • Console: Mini-USB (Front)
  • Storage: USB (Front)
  • Single-pane-of-glass NMS300 management platform with mass-configuration support
  • Dual firmware image and configuration file for updates with minimum service interruption
