Icron Technologies EL5363 HDMI plus USB 2.0 100m CAT 5e/6/7 KVM Extender

Product Code: IC 00-00388

Key Features
  • Long Distance: Video and USB over a single solid core shielded CAT 5e/6/7 cable at distances up to 100m (330ft)
  • Full uncompressed 1080p or 1920 x 1200 resolution HD video
  • 3D
  • 4Kp30
  • Deep Color
  • x.v. Color
  • Lip Sync Pass-through
  • CEC Pass-through
  • HDCP Pass-through
  • USB 2.0 throughput support up to 40Mbps
$1,837.17 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

Icron Technologies EL5363 HDMI plus USB 2.0 100m CAT 5e/6/7 KVM Extender

The EL5363 KVM Extender features the latest and most robust HD video and USB extension technology from Icron Technologies. The EL5363 lets you place a computer up to 100m (330 ft) away from a workstation using a single CAT 5e/6/7 cable. The system supports full HD video and USB 2.0, providing the ability to control keyboards, mice, flash drives, audio peripherals and other USB 2.0 and 1.1 devices. This extender supports HDMI video features such as 1080p, 4Kp30, Deep Color and CEC/HDCP pass-through. This KVM extender is suitable for proAV, interactive digital signage, security, medical and industrial applications.

The EL5363 KVM Extender provides HDMI uncompressed HD video, and USB 2.0 up to 100 meters over a single CAT 5e/6/7 cable.  This extender supports HDMI video features such as 1080p, 4Kp30, Deep Color and CEC/HDCP pass-through. This KVM extender can be used in applications for proAV, interactive digital signage, security, medical, and industrial. There is no video degradation even at the full 100 meter distance.

ExtremeUSB® suite of features:

  • Transparent USB extension
  • True plug and play; no software drivers required
  • Works with all major operating systems:  Windows®, OS X®, and Linux®
Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

RANGE:
Direct Connect: Up to 100m (330 ft) over a single CAT 5e/6/7 cable
VIDEO:
Resolution: High Definition 4Kp30, 1080p, 1920 x 1200
Color: 36-bit, Deep Color, and x.v. Color
Depth: 2D and 3D
Latency: Less than 1ms
SPEEDS:
USB 2.0: Up to 40Mbps
USB 1.1: Up to 12Mbps
LEX:
Video Connector: 1 x HDMI
USB Connector: 1 x USB Type B Receptacle
Link Connector: 1 x RJ45
Dimensions: 112mm x 175mm x 30mm
Enclosure Material: Silver Anodized Aluminum
Power Supply: 100-240V AC input, 5V DC output
REX
Video Connector: 1 x HDMI
USB Connectors: 3 x USB Type A Receptacles
Link Connector: 1 x RJ45
Dimensions: 112mm x 175mm x 30mm
Enclosure Material: Silver Anodized Aluminum
Available Current: 500mA for each USB port
Power Supply: 100-240V AC Input, 5V DC Output
ENVIRONMENTAL:
Operating Temperature: 0°C ~ 40°C (32°F to 104°F)
Operating Humidity: 20% to 80% relative humidity, non-condensing
IN THE BOX:
Local Extender (LEX) Yes
Remote Extender (REX) Yes
USB cable Yes
HDMI cable Yes
Quick Start Guide Yes
Two international power adapters with country specific cord Yes
