Icron Technologies EL5353 DVI plus USB 2.0 100m CAT 5e/6/7 KVM Extender

Product Code: IC 00-00383

Key Features
  • Point-to-point video and USB extension up to 100m over a single CAT 5e/6/7 cable
  • Full uncompressed 1920 x 1200 resolution HD video
  • 24-bit color depth
  • USB 2.0 throughput support up to 40 Mbps
$1,837.17 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

Icron Technologies EL5353 DVI plus USB 2.0 100m CAT 5e/6/7 KVM Extender

The EL5353 KVM Extender System features the latest and most robust HD video and USB extension technology from Icron Technologies. The EL5353 lets you place a computer up to 100m (330 ft) away from a workstation using a single CAT 5e/6/7 cable. The system supports full HD video and USB 2.0, providing the ability to control keyboards, mice, flash drives, audio peripherals and other USB 2.0 and 1.1 devices.

The EL5353 extends DVI uncompressed HD video, audio and USB 2.0 up to 100 meters. This KVM extender can be used in applications for proAV, interactive digital signage, medical and industrial environments. The video resolution is 1920 x 1200 with 24-bit color depth and it can support USB 2.0 throughput up to 40 Mbps. The video quality remains high even at the full 100 meter distance.

ExtremeUSB® suite of features:

  • Transparent USB extension
  • True plug and play; no software drivers required
  • Works with all major operating systems:  Windows®, OS X®, and Linux®
Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

RANGE:
Direct Connect: Up to 100m (330 ft) over a single CAT 5e/6/7 cable
VIDEO:
Resolution: High Definition 1920 x 1200
Color Depth: 24-bit color depth
Latency: Less than 1ms
SPEEDS:
USB 2.0: Up to 40Mbps
USB 1.1: Up to 12Mbps
LEX:
Video Connector: 1 x DVI
USB Connector: 1 x USB Type B Receptacle
Link Connector: 1 x RJ45
Dimensions: 112mm x 175mm x 30mm
Enclosure Material: Silver Anodized Aluminum
Power Supply: 100-240V AC input, 5V DC output
REX:
Video Connector: 1 x DVI
USB Connectors: 3 x USB Type A Receptacles
Link Connector: 1 x RJ45
Dimensions: 112mm x 175mm x 30mm
Enclosure Material: Silver Anodized Aluminum
Available Current: 500mA for each USB port
Power Supply: 100-240V AC Input, 5V DC Output
ENVIRONMENTAL:
Operating Temperature: 0°C ~ 40°C (32°F to 104°F)
Operating Humidity: +20% ~ 80% (non condensing)
IN THE BOX:
Local Extender (LEX) Yes
Remote Extender (REX) Yes
USB cable Yes
DVI cable Yes
Quick Start Guide Yes
Two international power adapters with country specific cord Yes
