NETGEAR M4350-48G4XF 52-port Layer 3 Stackable Fully Managed Switch with 48 x 1G POE+ & 4 x 10GBASE-X SFP+

Product Code: NGR GSM4352-100AJS

Key Features
  • 48 Gigabit PoE+ ports with 4 10GBASE-X SFP+ uplinks.
  • 550W internal power supply providing 236W of PoE budget.
  • 2 slots for modular power supplies (1+1 redundancy and/or EPS share).
  • Any APS350W, APS600Wv2, APS920W, or APS2000W can be used.
  • The PoE budget can reach 1,440W, the redundant PoE budget can also reach 1,440W.
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover.
  • Layer 3 feature set includes static, policy-based, and dynamic routing.
  • NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations.
  • NETGEAR ProSAFE® Limited Lifetime Hardware Warranty.
  • Dimensions: 440x400x43.2 mm
  • Weight: 7.19Kg (15.85 lb)
$7,799.00 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Estimated Lead time 4-6 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

NETGEAR M4350-48G4XF 52-port Layer 3 Stackable Fully Managed Switch with 48 x 1G POE+ & 4 x 10GBASE-X SFP+

Groundbreaking AV GUI - A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant - NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design - Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration - Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.

Fast, Easy Configuration for AV Pros - A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

Focus on the Event, Not Fan Noise - Most models have quiet mode which greatly reduces fan noise.

Designed for AV Over IP Right Out of the Box - With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

Maximise Performance with Pro Wifi Access Points - Enable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.

What's In The Box:

  • 1 x M4350-48G4XF (GSM4352)
  • 1 x Power cord(s)
  • 1 x Console USB Type-C cable
  • 1 x Rack-mounting standard bracket set
  • 1 x Set of longer brackets for recessed mounting
  • 4 x Rubber footpads for tabletop installation
  • 1 x Installation guide
Warranty

We offer a Limited Lifetime warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Width

440mm

Depth

400mm

Height

43.2mm

Weight

7.19kg (15.85lb)

Primary Port Speed

1 Gigabit

Number of Ports

52 (48 x 1G PoE+, 4 x 10G SFP+)

PoE Ports / Budget

48 PoE+ (30W/port), 236W Base, up to 1,440W Budget

IGMP Support

Enhanced (NETGEAR IGMP Plus™)

Jumbo Frame Support

Yes, up to 12kb

AVB Support

Yes, included

Acoustics

Quiet Mode 33dB@25ºC

Power Consumption

With PoE: 348W/1186.68Btu/ hr

  Without PoE: 99W/310.86Btu/ hr
  Standby without any port connection: 48.5W/152.29Btu/ hr

PSU Compatible Models

APS350Wv1

  APS600Wv2
  APS920Wv1
  APS2000Wv1
