AMX MET-7E-WH - Metreau 7-Button Ethernet Keypad Black

Product Code: AMX FG5793-03-WH

Key Features
Metreau 7-Button Ethernet Keypad, Install in Decora-style wallplates, Black
Enquire Now
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

The MET-7E Metreau 7-Button Keypad offers 7 double-width buttons that can be used as an individual keypad or in conjunction with the 7 and 13-Button Metreau Ethernet Expansion Keypads. The Keypad connects to the controller via Ethernet, which simplifies installation and connectivity.

Great keypad for control of a variety of devices in applications such as hospitals, residences, MDUs and other applications.

Features

  • Connects via Standard Protocols (Ethernet) Simplifies cabling and installation by minimizing cable runs
  • Daisy Chain up to Three Keypads Provides the ability to connect up to three keypads using one IP address
  • Fits in Decor Style Wall Plates Simplifies installation and looks great
  • Blue LEDs Glow to Indicate Button Selection Improves usability by confirming the user's choice selection
  • Bottom Button Can Act as Single or Two Buttons Provides added flexibility to the configuration



NOTE: Keypad wallplates not included. See ALD-CW-1, ALD-CW-2, ALD-CW-3.

Harman Professional University certifications required to purchase this product. Please contact your Account Manager to learn more.

Warranty

We offer a 3 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Dimensions (HWD) Keypad and Mounting Plate: 4" x 1 3/4" x 1" (10.3 cm x 4.5 cm x 2.5 cm)
Mounting Mounts into standard decor-style wallplates
Front Panel Components Pushbuttons available in a variety of field replaceable pre-printed buttons with blue LED indicators
Rear Panel Components (1) RJ-45 Ethernet Connector, 10/100, (2) 8-pin, 0.100 (2.54 mm) IDC-type male header
Power PoE (Power over Ethernet), 802.3af, class 0, Power Connector: (1) RJ-45 Ethernet Connector, 10/100
FG Numbers

FG5793-03-WH (White)
FG5793-03-BL (Black)
