AKG PCC130 SW High performance boundary layer microphone with on off switch

Product Code: AKG 3333H00010

Key Features
Low profile boundary layer mic, XLR version, with switch
$1,337.99 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

The PCC130 and the PCC130 SW are cardioid boundary layer microphones of professional quality that, due to their small size, fit perfectly on small tables. Thanks to low self-noise and very high sensitivity, the microphone picks up even distant voices clearly and naturally. A bass-tilt switch allows the user to tailor the low-end response and reduce subsonic noise.

The PCC130 SW has a silent-operating programmable membrane switch that can be configured for touch on/off, momentary on or momentary off. A high-intensity LED lights when the unit is on. For easy installation, both microphones offer an XLR connector and a detachable cable.

Features

Cardioid polar pattern

Reduces background noise and feedback

PCC® (Phase Coherent Cardioid®) technology

For optimum speech intelligibility

Three-position bass-tilt switch

For optimized suppression of subsonic noise

Silent-operating on/off switch (PCC130 SW only)

To reduce the number of simultaneously open mics

Detachable cable

Easy to install and service

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Audio frequency bandwidth 50 - 20000 Hz
Equivalent noise level 22 dB-A
Sensitivity 22 mV/Pa
Signal to Noise 72 dB-A

Dimensions

Length 89 mm
Width 64 mm
Height 25 mm

Design

Finish satin black

Audio Output

Type Switchcraft TB3M
Gender Male
Contacts 3-pin

Powering Interface

Voltage 12 to 48 V

Application

Conferencing Yes

Device

Boundary Layer Microphone Yes
