AKG PCC130 High performance boundary layer microphone

Product Code: AKG 3334H00010

Key Features
Low profile boundary layer mic, XLR version
$1,257.43 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

The PCC130 and the PCC130 SW are cardioid boundary layer microphones of professional quality that, due to their small size, fit perfectly on small tables. Thanks to low self-noise and very high sensitivity, the microphone picks up even distant voices clearly and naturally. A bass-tilt switch allows the user to tailor the low-end response and reduce subsonic noise.

The PCC130 SW has a silent-operating programmable membrane switch that can be configured for touch on/off, momentary on or momentary off. A high-intensity LED lights when the unit is on. For easy installation, both microphones offer an XLR connector and a detachable cable.

Features

Cardioid polar pattern

Reduces background noise and feedback

PCC® (Phase Coherent Cardioid®) technology

For optimum speech intelligibility

Three-position bass-tilt switch

For optimized suppression of subsonic noise

Silent-operating on/off switch (PCC130 SW only)

To reduce the number of simultaneously open mics

Detachable cable

Easy to install and service

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Trade Terms
This item is a firm order product, meaning it cannot be cancelled or returned once the purchase order is processed, except in cases of defect. Please verify that part numbers and descriptions are accurate before placing your order. For any confirmation or additional information, please contact AV Sales at 1800 00 77 80.
Audio frequency bandwidth 50 - 20000 Hz
Equivalent noise level 22 dB-A
Sensitivity 22 mV/Pa
Signal to Noise 72 dB-A

Dimensions

Length 89 mm
Width 64 mm
Height 25 mm

Design

Finish satin black

Audio Output

Type Switchcraft TB3M
Gender Male
Contacts 3-pin

Powering Interface

Voltage 12 to 48 V

Application

Conferencing Yes

Device

Boundary Layer Microphone Yes
