AKG PZM185 Hemispherical boundary layer microphone

Product Code: AKG 3324H00010

Key Features
Cost-effective boundary layer microphone, XLR version
$912.70 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

The PZM185 is a Pressure Zone Microphone® designed for applications such as group discussions, interviews, broadcast and home video production. The paddle can be detached, which makes it nearly invisible when mounted on tables, floors, walls, lecterns or cameras.

The PZM185 is powered by either an internal AAA 1.5V battery or 12 48V phantom power. It provides a wide, smooth frequency response and is protected against static and RFI. The XLR output is balanced and low-impedance, which allows long cable runs without hum pickup or high-frequency loss.

Features

Hemispherical polar pattern

For clear, intelligible pickup of speech

Universal power concept

Works with battery or phantom power

Low-impedance XLR-type output

No hum pickup or high-frequency loss

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Audio frequency bandwidth 50 - 16000 Hz
Equivalent noise level 21 dB-A
Sensitivity 0.8 mV/Pa
Signal to Noise 73 dB-A

Dimensions

Length 150 mm
Width 87 mm
Height 19 mm

Design

Finish satin black

Audio Output

Type Balanced XLR
Gender Male
Contacts 3-pin

Powering Interface

Voltage 12 to 48 V

Device

Boundary Layer Microphone Yes
