AKG PCC170 Professional boundary layer microphone

Product Code: AKG 3331H00010

Key Features
Surface-mount supercardioid boundary layer mic, XLR version
$1,305.28 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

The PCC170 and the PCC170 SW are professional boundary layer microphones with supercardioid polar pattern to minimize background noise and feedback. The microphones are designed for use on boardroom tables or lecterns. Both microphones provide a bass-tilt switch, allowing the user to tailor the low-end response and reduce subsonic noise. The included RFI suppression ensures trouble-free operation even with active cell phones nearby.

The PCC170 SW has a silent-operating programmable membrane switch that can be configured for touch on/off, momentary on or momentary off. For easy installation, both microphones offer an XLR connector and a detachable cable.

Features

Supercardioid polar pattern

Offers high gain before feedback

PCC® (Phase Coherent Cardioid®) technology

For optimum speech intelligibility

Three-position bass-tilt switch

For optimized suppression of subsonic noise

Silent-operating on/off switch (PCC170 SW only)

To reduce the number of simultaneously open mics

Detachable cable

Easy to install and service

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Audio frequency bandwidth 50 - 20000 Hz
Equivalent noise level 22 dB-A
Sensitivity 22 mV/Pa
Signal to Noise 72 dB-A

Dimensions

Length 123 mm
Width 86 mm
Height 23 mm

Design

Finish black

Audio Output

Type Switchcraft TB3M
Gender Male
Contacts 3-pin

Powering Interface

Voltage 12 to 48 V

Application

Conferencing Yes

Device

Boundary Layer Microphone Yes
