NETGEAR 10GBASE-LR SFP+ Transceiver- SINGLE MODE LC GBIC

Product Code: NGR AXM762-10000S

Key Features
  • 10 Gigabit Ethernet “short range” fiber connectivity
  • Fits into SFP+ interfaces of M5300, M7100 and M7300 series Managed Switches
  • Fits into SFP+ interfaces of select Smart and Plus Switches
  • Drives 10 Gigabit Ethernet up to 10 km (6.2 miles) distances with 9/125µm single mode fiber cables
  • LC duplex connector
$1,549.00 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Estimated Lead time 4-6 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

NETGEAR 10GBASE-LR SFP+ Transceiver- SINGLE MODE LC GBIC

NETGEAR ProSafe 10 Gigabit SFP+ transceivers fit into M5300, M7100 and M7300 series standard SFP+ interfaces, providing hot-swappable installation and removal. Select Smart switches and Plus switches will also connect 10 Gigabit SFP+ transceivers.

The 10 Gigabit small form-factor pluggable (SFP+) module provides a fullduplex 10G bps each direction for Ethernet operation on NETGEAR managed switches. The switch will automatically detect the AXM762, so you can simply plug it into an available module slot.

Warranty

We offer a 5 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Standards IEEE 802.3ae 10GBase-LR
Wavelength 1310nm
Weight 19.2g
Dimensions (H x W x D) 0.46” x 0.53” x 2.19” (11.9 mm x 13.7 mm x 55.7 mm)
Operating temperature 32 -158º F (0 - 70ºC)
Operating relative humidity 85% @ (25ºC)
Storage temperature 32 -185 ºF (0 - 85ºC)
Operating Distance 2m - 10km for 9/125 um SMF
Connectors LC for 9um/125um single mode cable
Power Consumption <1.5w
MTBF  4,986,536 hr (569 years)
Safety Certification UL 1950 CSA 22.2 No. 950
Environmental Compliance RoHS
