JBL Control SB2210 - Dual 10 Inch Compact Subwoofer Black

Product Code: JBL CTRLSB2210-BK

Key Features
Compact, Low Profile, High-Power Subwoofer with 2 x 250mm (10 Inch) Woven-Fiberglass Cone Drivers. 500 Watts Cont. Pink Noise Power Handling (2000W peak), 13 M6 Suspension Points, feet, Optional U-bracket. 38 Hz-500 Hz Frequency Range, 355 x 590 x 570 mm, (14 x 23.3 x 22.5 In). Black. Priced and sold individually.
$2,726.44 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Estimated Lead time 6-8 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

Dual 10" Compact Subwoofer

The Control SB2210 provides low frequency reinforcement for a wide variety of sound system applications. Its compact size, high output and outdoor capable design makes it one of the most versatile subwoofers in the installation market.

Features

  • 2 x 250 mm (10 in.) Woven Fiberglass Cone LF Drivers
  • 500 Watts Power handling
  • Frequency Response Down to 38 Hz
  • 13 x M6 Insert Points Including Inserts for Optional U-Bracket
  • Compact, Low Profile Design
Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Frequency Range (-10 dB) 38 Hz - 500 Hz
Frequency Response (-3 dB) 48 Hz - 95 Hz
Power Rating 500W (2000W peak) Continuous Pink Noise (2 hrs) 1000W Continuous Program(2 hrs) 400W (1600W peak) Continuous Pink Noise (100 hrs)
Maximum Input Voltage 60.0VRMS (2 hrs), 120V peak
Sensitivity 95 dB, 1W @ 1m in half-space (2 loading, average 50 90 Hz)
Max SPL 122 dB in half-space (2 loading)
Nominal Impedance 8
Minimum Impedance 7.2 at 160 Hz
Recommended Filter 45 Hz, 24 dB/oct high-pass filter
Low Frequency Two 250 mm (10 inch) diameter LF drivers, long-excursion design, woven fiberglass cone, highly damped butyl rubber surround, linear suspension spider , high temperature anodized aluminum voice coil former, high-temp voice coil wire and coil adhesive, FEA optimized motor construction, aluminum conductive ring.
Enclosure Material High Impact PolyStyrene (HIPS) w/ 10% glass fill and internal 8 mm polyurethane co-mold, painted with highly-UV-resistant paint on white (-WH) model for maximum UV fade resistance.
Grille Thermoset composite coated steel, zinc-plated, 3-layer foam backing.
Environmental IP-45 rating per IEC529 when installed with included MTC-PC2 terminal panel cover. Exceeds MilSpec 810 for humidity, salt spray, temperature & UV. Passes Mil-STd-202F for salt spray.
Terminals Screw-down terminal strip, zinc plated copper base, nickel-plated metal screws/washers. Accepts up to 9 mm outside, 4 mm inside open lug (#6, #8 or #10 lug), plus bare wire (up to 12 AWG/2.5mm2). Included MTC-PC2 and optional MTC-PC3 protective covers available to provide sealed entrance for additional weather protection.
Agency Rating ROHS-compliant. Optional MTC-SBT300 transformer is UL recognized per UL1876.
Colors Black or white (-WH)
Dimensions (H x W x D) 355 x 590 x 570 mm (14 x 23.3 x 22.5 in.)
Net Weight 23.31 kg (51.4 lb)
Shipping Weight 25.85 kg (57.0 lb)
Included Accessories 1 pc MTC-PC2 input panel cover, 4 pcs floor standing feet 4 pcs beveled washers.
Optional Accessories MTC-210UB (&-WH) U-BracketMTC-SBT300 70V/100V Transformer, 300W multi-tap, installs onto inside of back input panel using included 4 studs.Transformer Taps:70V: 300W, 150W, 75W, 38W100V: 300W, 150W, 75W
