AKG C747 V11 Professional shotgun condenser microphone

Product Code: AKG 2226H00110

Key Features
Professional shotgun condenser microphone
$2,465.89 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

The C747 V11 is a professional shotgun condenser capsule with a flat frequency response and a clean off-axis response. Due to its brilliant sound reproduction, it is perfect for guitar, piano, drum and overhead recordings. Thanks to its inconspicuous appearance, it is also widely used as a speech and lectern microphone.

The C747 V11 features an integrated RFi shield to block out unwanted interference from mobile phones, wireless microphones and other wireless devices. The C747 V11 ships with an extensive accessory set including a shock mount adapter, mini-gooseneck, stand adapter, mounting clamp, thread link and windscreen.

Features

Enhanced, hypercardioid polar pattern

Eliminates noise from the sides

RFi shielding technology

Prevents interference noise from mobile phones

Withstands high sound pressure levels

For close-up miking of loud sources

Small and inconspicuous

For mobile and installed solutions

Extensive accessory set included

For a wide range of mounting possibilities

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Audio frequency bandwidth 30 - 18000 Hz
Equivalent noise level 32 dB-A
Sensitivity 8.5 mV/Pa
Signal to Noise 73 dB-A
Bass cut filter 150 Hz
Electrical impedance 400 Ohms
Recommended load impedance 1500 Ohms
Polar Pattern Hypercardioid

Dimensions

Diameter 9 mm
Net Weight 25 g

Design

Finish stage blue

Audio Output

Type Balanced XLR
Gender Male
Contacts 3-pin

Powering Interface

Voltage 9 to 52 V
Current 2 mA

Application

Pro Studio Yes
Presentation Yes

Instrument

Drums / Percussion Yes
Piano / Strings Yes

Device

Shotgun Microphone Yes
