Neomounts Fixed Flat Screen Heavy Duty Wall Mount 55 to 110 Inch

Product Code: NST WL30S-950BL19

Key Features
  • Neomounts Select fixed wall mount
  • For 55-110" screens
  • Maximum weight capacity of 160 kg
  • Black
$574.53 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

Neomounts Fixed Flat Screen Heavy Duty Wall Mount 55inch to 110inch

The Neomounts Select WL30S-950BL19 is a fixed heavy-duty wall mount for flat screens up to 110" with a maximum weight capacity of 160 kg. It is possible to install the screen in both portrait and landscape orientation. The mount features individual height adjustable brackets and level adjustment is available for the perfect installation.

The WL30S-950BL19 has a depth of 6,5 cm and is, thanks to the included vertical extension brackets, suitable for screens that meet VESA hole pattern 100x100 to 1500x900 mm. Due to the unique extendable design, the mount can be adjusted to a wide range of screens dimensions; from 55" up to 110". It is possible to lock the mount using a padlock (not included).

The mount features a nifty magnetic pull & release system, that allows you to attach the TV in a wink of an eye and secure the TV in safe and solid manner. Afterwards, the pull & release straps can be easily hidden behind the screen by clicking the magnet to the mount. A separate spirit level tool is included with the wall mount to ensure easy installation of the mount.

Warranty

We offer a 5 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

General
Min. screen size 55 inch
Max. screen size 110 inch
Max. weight 160 kg
Screens 1
VESA pattern 100x100, 100x150, 100x200, 200x100, 200x200, 200x300, 200x400, 300x100, 300x200, 300x300, 300x900, 350x350, 400x200, 400x300, 400x400, 400x500, 400x600, 440x400, 460x640, 500x400, 600x200, 600x300, 600x400, 600x500, 600x600, 680x300, 800x200, 800x400, 800x500, 800x600, 800x800, 900x600, 1000x400, 1000x600, 1000x700, 1000x800, 1200x600, 1200x800, 1200x900, 1400x800, 1500x600 mm
VESA minimum 100x100
VESA maximum 1500x900
Distance to wall 6,7 cm
Functionality
Type Fixed
Height adjustment 0-2 cm
Width adjustment 89,3-160 cm
Rotate (degrees) +3°, -3°
Height 93,6 cm
Width 160 cm
Depth 6,7 cm
Adjustment type Micro adjustment
Lockable Lockable - Security screw included
Article number WL30S-950BL19
EAN 8717371449551
Colour Black
Main material Steel

*Please note: The inch sizes stated are just an indication, combined with the weight and VESA sizes. The maximum weight and VESA size are absolute restrictions for the products and should not be exceeded.
