JBL CSA 2120R - Commercial Series 2-Channel 120W Power Amplifier

Product Code: JBL CSA2120R

Key Features
2 x 120 Watt Amplifier at 4/8 Ohms
$1,575.83 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

The CSA-2120 is a professional-grade power amplifier built for commercial and installed sound applications.  The amplifier is a two-channel model providing simple analog front-end processing with a switch-mode universal power supply.

Features

  • 2 x 120W at 4/8Ohms
  • Plenum Rated (UL2043)
  • Compact size and light weight
  • Convection Cooled
  • Auto-standby mode for energy savings
  • Summing RCA inputs for each channel
Warranty

We offer a 3 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Output 120W @ 4/8 Ohms (1kHz Power, THD+N<0.5%)
Frequency Response +/- 1dB (@1W into 4 or 8 Ohms)
Load Impedance Stable from 2 - 16 Ohms
Sensitivity 1.4Vrms
Signal to Noise Ratio Greater than 100 dB - 1kHz, A-weighted
Input Impedance Balanced 20K Ohms/Unbalanced 10K Ohms
Max Input +20dBu Typical
Dimensions 8.2" x 1.7" x 7" (209 mm x 44 mm x 178 mm)
Shipping Weight 2.9 Lbs (1.3 Kg)
Included Accessories Rack mounting kit
