JBL 8124 - 4 Inch Full-range In-Ceiling Loudspeaker - Priced as Each Sold as 4 Pack

Product Code: JBL 8124

Key Features
4" Open-Back Ceiling Speaker. 70V/100V taps at 6W, 3W, 1.5W (plus 0.75W at 70V), high 93 dB sens, 60 Hz to 18 kHz, for non-plenum applications, 1.2 kg (2.5 lb). (Priced as each, sold in packages of 4 pcs)
$126.85 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

4-inch, Full-range, In-Ceiling Loudspeaker

The 8124 is a 4-inch, full-range, cost-effective loudspeaker for commercial applications. The 8124 features high-fidelity performance in an easy to install package. The system's high sensitivity drivers deliver maximum sound levels using minimal amplifier power. With its contemporary grill design, 70V/100V taps and an open-back design, the 8100 series brings elegance and performance to basic commercial sound systems, or any application not requiring a backcan for installation.

Features

  • Clear, High-Fidelity Performance
  • Dog-ears for easy Blind Mount Installations
  • High Sensitivity (93 dB, 1W, 1m) for Maximum Power Efficiency
  • 6W Transformer for use of 70V / 100V Distributed Lines

Important Order Information: The price displayed for this item is the price of a singe unit. However, this item is packaged and sold as a carton of 4 units. Please note, this item must be purchased in multiples of 4 units.

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Component 4 in (100 mm), Full-range Driver
Frequency Range 60 Hz 18 kHz
Sensitivity 93 dB (1 kHz 8 kHz), 1W, 1M
Coverage 130 conical
70V/100V Taps 6W, 3W, 1.5W (0.75W at 70V only)
Termination Bare wires
Dimensions (Diameter x Depth) 8.1 in (206mm) x 3.5 in (89mm)
Weight 2.5lb (1.2kg)
Included Accessories Sculpted Grille
Optional Accessories MTC-8124C C-ring, MTC- Rail tile rails
