Crown DCI8300DA - 8-Channel 300W Power Amplifier with DANTE

Product Code: CWN DCI8X300DA

Key Features
Eight-channel, 300W @ 4 ohms Power Amplifier with Dante / AES67 Networked Audio, and 70V/100V
$15,243.31 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

For applications that require Dante or AES67 networked audio, the Crown DriveCore Install DA Series provides a balanced combination of output power, channel count and speaker load flexibility along with proprietary DriveCore® technology for superb efficiency and exemplary audio quality. The DCi DA Series includes a high-powered DSP with JBL speaker tunings, network control/monitoring, and the ability to drive 2/4/8/16 ohm, 70V and 100V speaker loads. The amp s advanced capabilities and support for Dante Domain Manager makes it perfect for installations that have standardized on Dante for networked audio transport.

Features

  • Integrated Dante™ / AES67 Networked Audio Simplifies installation by enabling Dante / AES67 networked audio signals to be sent directly to the amplifier. Provides flexibility of installation options available with our expansive line-up of DriveCore Install amplifiers. Includes support for Dante 4.0 firmware for integration with Dante Domain Manager.
  • Network Configuration, Monitoring & Control Better monitoring, control and audio manipulation with the HiQnet™ protocol over standard TCP/IP network. The HiQnet Audio Architect software allows for remote configuration, monitoring, and control of all aspects of the DCi-DA Series amplifiers.
  • Programmable General Purpose Input/Output Port GPIO ports can be configured in many different ways, such as volume controls, recall presets, or to report errors to third-party control system.
  • Digital Signal Processing  DSP capabilities include the following:
    • LevelMAX Limiters
    • Input/Output EQ
    • Crossover
    • Delay
    • Matrix Router
    • Speaker Line Monitoring
    Warranty

    We offer a 3 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

    • Redundant, independent Dante / AES67 ports
    • Primary & Secondary
    • Will accept 48khz or 96khz
    • Capable of sending out Dante / AES67 audio from analog inputs pre/post processing (@ 48kHz)
      • Audio Architect Control and Monitoring
      • DriveCore Amplifier Technology
      • Universal PFC Power Supply
      • DSP
    • 48kHz processing
    • 20 Presets
    • Input router
      • High, medium, and low priority inputs
    • Input delay up to 2s
    • Input EQ
    • Crossover
    • Output EQ
    • Output Delay up to 100ms
    • LevelMAX limiter
    • Load Monitoring
      • Pilot tone
    • Normal
    • Burst
      • Continuous Load Monitoring
      • Sweep Load Monitoring
    • Channel Auto-Standby
    • Speaker Tunings
      • Aux-Port
    • Sleep contact closure
    • Amp Status output
      • Removable air filters
      • Front panel LED indicators
      • AES67 Compatible
