AKG CS3BU Conference base unit

Product Code: AKG 3361H00250

Key Features
The CS3 BU is the base unit for the CS3 conference system and provides all the necessary inputs and outputs to manage a conference for up to 60 microphone stations.
$4,080.47 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

The CS3 BU is the base unit for the CS3 conference system and provides all the necessary inputs and outputs to manage a conference for up to 60 microphone stations. It is the interface to all audio devices in a meeting room and offers a RS232 interface to connect an optional camera control system.

The CS3 BU can even work in a stand-alone mode in four selectable operating modes offering maximum flexibility in conference management. With the NOM limitation function, the maximum number of active stations can be programmed to 1, 2, 4 or 6 simultaneous open microphones.

Features

All in one conference controller

For discussion systems of up to 60 stations per base unit

Four selectable operating modes

For flexible conference management

Connects to all relevant devices

e.g. PA, recording, ext. audio and camera control systems

Compact 19" housing

For easy rack mounting

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Power Supply SMPS 100-240V (50Hz / 60 Hz) 3A
Static Consumption 13W
Nominal Power Consumption 320W
Output Power ≤90W / 24V each way
Mode Balanced / Unbalanced
Frequency Response 50Hz-20kHz
S/N >80dB
Harmonic Distortion <0.5%
Harmonic Distortion at Overload <1%
Crosstalk Attenuation (1kHz) >50dB
Operating Temperature 0°C - 40°C at 95% relative humidity (non-condensing)

Dimensions

Length 482 mm
Width 281 mm
Height 88.4 mm
Weight 5.2kg
